Features

• Outer cabinet stove enameled after proper antirust phospating Process.
• Transformer are vacuum impregnated with high class varnish for reliability and long life.
• Provide sine wave output irrespective of quality of input wave shape.
• Intrinsic current limiting & short circuit protection.
• High input voltage control range for load less than reted load.
• Short-term over load capacity.

Specification :	Capacity : 500VA to 10 KVA
Input Voltage	180-260 Volt
Output Voltage	220/230 Volt ±1%
Frequency	50Hz ± I 1%
Response Time	30 Milliseconds
Efficiency	95% under full load conditions
Output Wave form	Sinusoidal
Load Power Factor	0.75% log to 0.9% load
Ambient Temp.	-5o to 50oC
Wave form  Distortion	Less Than 4% under full load
Effect of Line Frequency	1.5% (appx.) Change in output Voltage For Every 1%Change in Line Frequency
Also Available	170V, 160V and 140 Volt.
Application	Computer, Epabox, Tele Communication, Medical Equipments and fax Machine etc.
